LC Connector 10G BIDI Sfp Transceiver Module Tx1270 1Rx1330NM

Product Categories
Shenzhen linkopto Technology Co. Ltd
Contact Now

LC Connector 10G BIDI Sfp Transceiver Module Tx1270 1Rx1330NM

  • 1
  • 2

Brand Name : Linkopto , or OEM

Model Number : EXB23X-3LCD20

Certification : CE, FCC, ROHS, TUV, ISO9001

Place of Origin : China

MOQ : 1pcs

Price : Get latest price

Payment Terms : T/T, WU, PayPal, Moneygram, L/C

Supply Ability : 20,000pcs per week

Delivery Time : 1~3 working days

Packaging Details : 10pcs/ plastic tray or individual package

Product Name : 10G XFP BIDI TRANSCEIVER

Model Name : EXB23X-3LCD20

Wavelength : Tx1270/1Rx1330NM

Data Rate : 10G

Transmission Distance : 20KM

Connector Type : Simplex LC

DDM : with

Working Environment : Commercial 0~70℃

Compatibility : Cisco

Contact Now

10Gbps XFP Bi-Directional Transceiver 20KM Reach

Rx1270/Rx1330 nm

Features

Ø Supports 9.95Gb/s to 10.5Gb/s bit rates

Ø Hot-pluggable XFP footprint

Ø Maximum link length of 20KM with SMF

Ø 1270nm DFB laser Transmitter ,and 1330nm Receiver

Ø XFP MSA package with LC connector

Ø No reference clock required

Ø Loop Back Support.

Ø +3.3V,+1.8V power supply

Ø Power dissipation <2W

Ø Compatible with RoHS

Ø Built-in digital diagnostic functions

Ø Temperature range 0°C to 70°C

Applications

Ø 10GBASE-LR at 10.3125Gbps

Ø 10GBASE-LW at 9.953Gbps

Ø 10GBASE-BX 10G Ethernet

Product Description

compliant with the IEEE803.3ae 10Gbase-Bx. and transmission distance up to 20KM on SMF.

The transceiver module comprises a transmitter with a 1270nm DFB laser transmitter, an integrated 1330nm detector preamplifier(IDP) mounted in an optical header and a limiting post-amplifier IC. Transmitter and receiver are separate within a wide temperature range of 0℃ to +70℃ and offers optimum heat dissipation and excellent electromagnetic shielding thus enabling high port densities for 10GbE systems.

​Quality Control

LC Connector 10G BIDI Sfp Transceiver Module Tx1270 1Rx1330NMLC Connector 10G BIDI Sfp Transceiver Module Tx1270 1Rx1330NM

LC Connector 10G BIDI Sfp Transceiver Module Tx1270 1Rx1330NMLC Connector 10G BIDI Sfp Transceiver Module Tx1270 1Rx1330NM

Linkopto NO
Date Rate
Wavelength(nm)
Source
Connector
Reach
BIDI-XFP-LR-27
10G
Tx1270/Rx1330
DFB+PIN
LC
20km
BIDI-XFP-LR-33
10G
Tx1330/Rx1270
DFB+PIN
LC
20km
BIDI-XFP-ER-27
10G
Tx1270/Rx1330
DFB+PIN
LC
40km
BIDI-XFP-ER-33
10G
Tx1330/Rx1270
DFB+PIN
LC
40km
BIDI-XFP-ER+-27
10G
Tx1270/Rx1330
DFB+APD
LC
60km
BIDI-XFP-ER+-33
10G
Tx1330/Rx1270
DFB+APD
LC
60km
BIDI-XFP-ZR-49
10G
Tx1490/Rx1550
EML+APD
LC
80km
BIDI-XFP-ZR-55
10G
Tx1550/Rx1490
EML+APD
LC
80km
